MIL-DTL-83196C(USAF)
TABLE II. Sewing operations for underpants. - Continued
Stitches
Sequence
Description of Operation
Stitch
Seam and
Number
Type
Stitching
per Inch
Type
6
Overedge stitch and join anklet.
a. Overedge stitch the raw edges of the knitted anklets
504
EFd-1
20-24
catching both edges of the knit.
or
505
b. Join the anklets to the leg terminals of the underpants.
301
SSa-1
12-14
or
504
c. Cover stitch the raw seam edges.
402,
SSh-2(a)
20-24
406,
or
606
7
Attach label to underpants. Center the label over the back
301
LSbj-1
8-10
seam 2-1/2 ± 1/4 inches down from the finished top of the
or
304
underpants. Join the label to the underpants with a single
row of stitching on all four sides.
8
Trim thread ends. Trim all thread ends and remove loose
threads.
9
Cut undershirt. Cut the back, front, sleeves, and knit collar.
10
Overedge stitch undershirt. Overedge stitch all raw edges of
504
EFd-1
8-10
the back, front, and sleeves of the undershirt, including the
or
underarm vent cutouts.
505
11
Join undershirt.
a. Join the front to the back of the shoulders.
606
FSa-1
12-14
b. Join the sleeves to the armholes.
606
FSa-1
12-14
c. Join the side seams.
606
FSa-1
12-14
d. Join the wristlets to the sleeve ends.
606
FSa-1
12-14
e. Join the ends of the knit collar with a single row of
301
SSa-1
8-10
stitching 1/2 inch from the edge.
12
Overedge stitch and join collar to undershirt.
a. Fold the collar lengthwise with the raw edges of the
504
EFd-1
20-24
seam to the inside and overedge stitch the two edges
or
together.
505
b. Join the collar to the neck opening, joining seam for
606
FSa-1
12-14
the collar to be the back of the undershirt.
13
Attach label to undershirt. The label shall be positioned at
301
LSbj-1
8-10
the center of the back 1 ± 1/4 inch down from the collarline
or
304
and stitched to the undershirt with a continuous row of
stitching on all four sides.
7
