MIL-DTL-81905G(AS)
No.
Description of Operation
Stitch
Seam
Stitches
Type
and
Per Inch
Stitching
Type
6
(b) Trim the fastener tape, if necessary, to fit the leg
301
LSd-1
8-10
(cont'd)
lacer covers at the top and the bottom. Turn each leg
lacer cover under 3/8 inch. Sew the hook fastener
tape to each leg lacer cover, at the pattern location,
with a single row of stitching 1/8 inch from the edge
on all four sides.
(c) Bind each leg lacer cover at each end with bias
301
BSc-1
10-12
binding in 3.4.2 (finished dimension 5/16 inch) with
a single row of stitching 1/16 inch from the edge.
Before completing the stitching of the binding tape at
the top and the bottom of each lacer cover, fold the
raw edges of each end of the binding (two ends per
lacer cover) approximately 1/2 inch, so that no raw
edges are exposed, and complete the stitching of the
binding to the fastener tape.
(d) Select the fastener tapes for the leg lower lacer
covers in accordance with table IV.
(e) Trim the fastener tape, if necessary, to fit the leg
301
LSd-1
8-10
lower lacer covers at the top and the bottom. Turn
each leg lower lacer cover under 3/8 inch. Sew the
hook fastener tape to each leg lower lacer cover, at
the pattern location, with a single row of stitching 1/8
inch from the edge on all four sides.
(f) Bind each leg lower lacer cover at each end with
301
BSc-1
10-12
bias binding in 3.4.2 (finished dimension 5/16 inch)
with a single row of stitching 1/16 inch from the
edge. Before completing the stitching of the binding
at the top and the bottom of each lacer cover, fold the
raw edges of each end of the binding (two ends per
lacer cover) approximately 1/2 inch so that no raw
edges are exposed, and complete the stitching of the
binding to the fastener tape.
7
Hem Body Bladder Casing
Note: The term "bladder casing" in this table refers to
the pattern labeled "bladder cover" to differentiate
between "lacing covers", "body cover", and "leg
cover".
19
