MIL-DTL-81905G(AS)
TABLE V. Elastic for kneeboard subassembly.
Cut Length Elastic
Cut Length Webbing
(inches) 1/
(inches)
Size of anti-G
Garment
2 each
4 each
Small Regular
7¾
2¾
Small Long
7¾
2¾
Medium Regular
8¼
2¾
Medium Long
8¼
2¾
Large Regular
9¼
2¾
Large Long
9¼
2¾
Large Extra Long
9¾
2¾
1/ These dimensions are approximate because the requirements of table III specify that
the respective free webbing ends of the elastic kneeboard assembly shall be trimmed, if
necessary, so that the elastic kneeboard subassembly lays flat across the thigh cover.
3.5 Design. As shown on drawing 1628AS100, the anti-G garment shall be a wrap-around
garment that extends from the waist to over the calves of the wearer. It shall have an inflatable
bladder that will cover the waist and the leg areas of the wearer and a connector that will provide
normal and emergency connection and disconnection of the bladder of the anti-G garment to and
from the air pressure source.
Both sides of the anti-G garment shall have external adjustment laces in the waist, thigh, and
calf areas; however, the adjustment laces shall have covers that can be unfastened for easy
accessibility. The anti-G garment shall have a pocket on the calf of each leg.
3.6 Dimensions, tolerance. Unless otherwise specified, the tolerances for all drawings,
patterns and operations shall be as specified in table VI, except the tolerance for all binding
operations shall be +1/16 -1/32″.
TABLE VI. Tolerance dimensions.
Dimension
Tolerance
±1/32 inch
1/16 inch or under
±1/16 inch
More than 1/16 inch but less than 2 inches
±1/8 inch
2 inches or more but less than 10 inches
10 inches or more but less than 30 inches
±¼ inch
±3/8 inch
30 inches or more but less than 60 inches
60 inches or more
±1 inch
11
