MIL-DTL-81905G(AS)
No.
Description of Operation
Stitch
Seam
Stitches
Type
and
Per Inch
Stitching
Type
5
Make Body Lacer Covers
Note: No. 5(b) shall be performed before No. 5(c) so
that the fastener tape will be sewn to the body lacer
covers before the body lacer covers are bound.
(a) Select the fastener tapes for the body lacer covers
in accordance with table IV.
(b) Trim the fastener tape, if necessary, to fit the
301
LSd-1
8-10
body lacer covers at the top and the bottom. Turn
each body lacer cover under 3/8-inch. Sew the hook
fastener tape to each body lacer cover, at the pattern
location, with a single row of stitching 1/8 inch from
the edge on all four sides.
(c) Bind each body lacer cover at each end with bias
301
BSc-1
10-12
binding in 3.4.2 (finished dimension 5/16 inch) with
a single row of stitching 1/16 inch from the edge.
Before completing the stitching of the binding at the
top and the bottom of each lacer cover, fold the raw
edges of each end of the binding (two ends per lacer
cover) approximately 1/2 inch, so no raw edges of
binding tape are exposed and complete the stitching
of the binding to the fastener tape.
6
Make Leg Lacer Covers and Leg Lower Lacer
Covers
Note: No. 6(b) shall be performed before No. 6(c) so
that the fastener tape will be sewn to the leg lacer
covers before the leg lacer covers are bound.
Note: No. 6(e) shall be performed before No. 6(f) so
that the fastener tape will be sewn to the leg lower
lacer covers before the leg lower lacer covers are
bound.
(a) Select the fastener tapes for the leg lacer covers
in accordance with table IV.
18
