MIL-DTL-83406C
TABLE II. Manufacturing operations. - Continued
Seam &
Stitch
Stitch
Stitches
Description of Operation
Type
Type
per Inch
No.
11. Assemble pockets contd.
c. Place the slide fastener at the marked location on
301
SSa-1
10-12
the pocket to the inside; join with a single row of
stitching 1/16 inch from the edge all around. (The
bridge end shall be at the lowest point on the pocket
opening.)
d. Slit through the center and diagonally at the
301
LSd-1
10-12
ends. Turn the fabric under approximately 1/4 inch;
sew with a single row of stitching 1/16 inch from the
folded edge.
e. Sew the bottom corners, the face sides of the
301
SSa-1
10-12
material together, with a single row of stitching 3/8
inch from the edge.
301
OSf-1
10-12
f. Raise the sides and the bottom edge of the
pockets, at the pattern marks, with a single row of
stitching 1/16 inch from the folded edge.
g. Thread a 5-inch length of the 5/16 inch wide
bartack
21-23
webbing for the pull thong through the pull of each
stitches
per
slide fastener. Fold the webbing in the center and
bartack at the ends and close to the pulls.
bartack
h. Cut four, 2-3/4-inch squares of the basic fabric to
301
LSa-1
10-12
reinforce the slide fasteners. Turn the outside
edges of each reinforcement under 1/4 inch on all
four sides and stitch two reinforcements to each
pocket with a box "X" stitch inside a box through all
thicknesses of leather, fabric, and zipper tape. The
reinforcements shall be positioned so that a
reinforcement will be adjacent to each end of the
metal portion of the slide fastener (centered from the
top and the bottom on the inside of the pocket).
12. Make leg loop tab assembly.
301
SSa-1
10-12
Cut two pieces of nylon tape in accordance with the
patterns, fold at the center, sew a box "X" 3/4 by 1-
1/4 inches, 1/8 inch from the folded edge. Punch a
hole diameter 1/8 inch in the center of box "X" stitch,
install
button
NASM27980-1B
and
socket
NASM27980-6B through the hole at center of box
"X" stitch.
19
