MIL-DTL-83406C
TABLE II. Manufacturing operations. - Continued
Seam &
Stitch
Stitch
Stitches
Description of Operation
Type
Type
per Inch
No.
10. Make leg protective cover.
a. Position a 1 inch square reinforcement of the
301
SSa-1
10-12
basic fabric, as marked on the patterns, so that the
center of the reinforcement will be 2-5/8 inches
down from the top of the leg protective fly finished
edge and on the inside. Sew with a single row of
stitching 1/8 inch from the edge.
b. Fold the leg protective fly cover lengthwise on
301
SSe-2(a)
10-12
the fold line, the face sides of the material together;
sew across the bottom and the top with a single row
of stitching 3/8 inch from the edge.
c. Turn and insert the stiffener, folding the raw
301
SSe-2(b)
10-12
edges to the inside enclosing the stiffener; sew all
around the top, the bottom, and the two sides with a
single row of stitching 1/8 inch from the edge. Sew
four additional single rows of stitching evenly
spaced from end to end.
d. Sew a box "X" 7/8 by 7/8 inch, 1/8 inch from the
301
SSa-1
10-12
edge of reinforcement described in Operation 13.a
with a single row of stitching.
e. Punch a holde diameter 1/8 inch in the center of
box "X" described in Operation 13.d. Install stud
NASM27980-7B and eyelet NASM27980-8B
through the hole at center of box "X" stitch, ensuring
the stud is on the side that matches with socket of
tab assembly.
301
SSa-1
10-12
f. Attach the slide fastener tape (with the slider
attached) to the back edge of the leg protective fly,
the open end at the bottom; sew with a single row of
stitching 1/8 inch from the edge.
11. Assemble pockets.
a. Position leather patch on pocket face aligning cut
301
SSa-2
8-10
edge of leather with pocket pattern markings. Stitch
leather to pocket with a single row of stitching 1/4
inch (±1/32 inch) from cut edge of leather.
b. Bind the side edges of the pockets with 5/16 inch
301
BSc-1
10-12
wide (finished) bias tape with a single row of
stitching 1/16 (±1/32) inch from the edge.
18
