MIL-DTL-83406C
TABLE II. Manufacturing operations. - Continued
Seam &
Stitch
Stitch
Stitches
Description of Operation
Type
Type
per Inch
No.
7. Make thigh take-ups - contd.
301
BSc-1
10-12
d. Bind all around the leg take-ups, catching the
ends of the slide fastener tapes in the binding, with
5/16 inch wide (finished) bias binding 1/16 (±1/32)
inch from the edge.
e. Thread a 5 inch length of the 5/16 inch wide
bartack
21-23
webbing for the pull thong through the pull of each
stitches
slide fastener. Fold the webbing in the center and
per
bartack at the ends and close to the pull.
bartack
8. Prepare slide fasteners for body and leg openings.
a. Select the slide fasteners for the body and the
leg openings in accordance with table I.
b. Prefold the slide fastener tapes for the leg
301
EFa-1
10-12
openings at the open ends with a triangular fold so
that the beaded edge of the tape is across the end
and the fold is to the inside. Sew with a single row
of stitching 3/32 (+1/32 or -1/16) inch from the edge.
Prefold and sew the slide fastener tape for the body
opening in the same manner as for the leg
openings, making certain that the fold is placed so
that the length of the slide fastener tape will be 8-5/8
(±1/8) inches.
c. Thread a 5-inch length of the 5/16 inch wide
bartack
21-23
webbing for the pull thong through the pull of each
stitches
slide fastener. Fold the webbing in the center,
per
bartack at the ends and close to the pulls.
bartack
d. Cut three, 6 inch long tapes from the 5/16 inch
301
SSa-1
10-12
wide webbing. Fold the tapes in the center to form a
loop; join, forming a box "X" stitch with a single row
of stitching 1/16 inch from the edge, to the
separating end of the slide fastener opposite the
sliders, with the ends of the tape down 5/8 inch from
the end of the slide fastener tape. Sew the tape to
the inside of the anti-g garment.
e. Sew the loops of the two tapes on the leg
301
10-12
opening slide fasteners closed by sewing both sides
of the loops with a single row of stitching 1/16 inch
from the edges.
16
