MIL-DTL-87174A(USAF)
4.5.3.3 Visual examination of components prior to assembly of helmet. The components identified
below shall be examined for defects prior to installation on the helmet (see 6.10).
a.
Molded shell, unpainted
b.
Helmet shell
c.
Visor, assembly, lightweight
d.
Lens covers, visor
e.
Absorbent liner assembly
f.
Pads, fitting, earcup
g.
Chin strap or nape strap
h.
Energy absorbing liner
i.
Edgeroll (gray leather)
j.
Lens stop
k.
Bayonet receiver kit
4.5.4 End-item visual examination. The complete helmet assembly, consisting of the items below,
shall be examined for defects, specified in table V, and cleanliness prior to packing and shipping.
The end-item shall also be visually inspected for compliance with commonly accepted
manufacturing and workmanship standards (see 6.11).
a.
Helmet Shell
b.
Edgeroll
c.
Earcup section fastener, pile fabric
d.
Visor assembly, lightweight
e.
Chin strap or nape strap
f.
Lens stop
TABLE V. Classification of defects, end-item visual examination.
Helmet shell
Any visor snap fastener missing
Scratched, scuffed, or abraded areas
Hardware not black as specified
Identification label missing, illegible, or not of permanent type.
Edgeroll (gray leather)
Color not as specified
Any crack, hole, or tear
Not properly secured to shell
Excessive glue on edgeroll
Earcup section fastener Pile fabric
Not properly secured to inside of helmet
Color not as specified
Improperly located in earcup section
14
