MIL-DTL-87174A(USAF)

TABLE IV. In�process visual examination - noted problems - Continued.

Chin strap or nape strap

Material not as specified

Any grommet incorrectly installed

Snap fastener insecurely set

Loose stitching, skipped stitches, or not back�stitched

Ends of webbing not seared

Lacing cord not seared properly

Lacing cord improperly laced

Buckle tab missing

Energy Absorbing Liner

Liner not properly aligned in shell

Any gaps between liner and shell exceeding 0.125 inch

Inner surface of liner not coated

Any fastener tape missing

Centerline beads not discernible

Size code letter not discernible

Liner not uniformly bonded to shell

Soiled or stained areas

Edgeroll (gray leather)

Color not as specified

Any crack, hole or tear

Not properly secured to shell

Excessive glue on edgeroll

Lens stop

Color not as specified

Any crack, hole or tear

Bayonet receiver kit

Spacer not black as specified

Any sharp edge or burr

Component missing

4.5.3.1 Visual examination of molded shell, unpainted. Prior to preparation for finishing the

molded unpainted helmet shell shall be examined as specified in table IV.

4.5.3.2 Visual examination of painted shell prior to installation of edgeroll. The helmet shell shall

be examined for defects as specified in table IV prior to installation of the edgeroll.
